Chassis Model

CA3251P25K15L3T1E5A80

Driving type

LHD (RHD is optional)

Cabin

Model JH6, COE design, fully welded steel, 1-bed flat roof sleeper, 4-point floating, coil spring (front)/air spring (rear)

With shock absorbers, 50-degree hydraulic cabin tilt system with manual support and safety lock, elevation

Front service panel with acoustic and thermal insulation, external sun visor made of aerodynamic impact-resistant plastic.

Engine

Make: XICHAI

4-stroke direct injection diesel engine

Engine model: CA6DM2-42, Euro 2, 420 HP

6-cylinder in-line engine with water cooling, turbocharging and intercooling.

Displacement: 11.05 L

Transmission

12JSD200TA-B, 12F & 2R

Direction

TRW TAS85 full hydraulic steering, adjustable tilt and telescopic column.

Rear axle

FAW φ 457

Ratio: 4,875

Propeller shaft

Double universal joint propeller shaft with gear-shaped coupling flange.

Chassis

Frame: Stair type, side rails of the channel section

Front suspension: parabolic springs with shock absorbers

Rear suspension: parabolic springs, two "V" rods and four "I" rods

Brake

Service brake: dual-circuit compressed air brake

Parking brake (emergency brake): spring energy, compressed air operating on the front axle and rear wheels.

Auxiliary brake: engine exhaust brake

Electricity

Operating voltage: 24 V, negative grounded

Input: 24 V, 5.4 Kw

Alternator: 3 phases, 28 V, 1500 W

Batteries: 2 x 12V, 165Ah

Cigarette lighter, horn, headlights, fog lights, brake lights, indicators, and reverse light.

Tires

12.00R20 radial tires with a spare tire.

Fuel tank

400L

Body size

5600*2300*1500mm, bottom 8mm, side 6mm #180 front lifting cylinder

Overall dimension

8500*2500*3500mm
